The ADL5610 is a single-ended RF/IF gain block amplifier that provides broadband operation from 30 MHz to 6 GHz. The ADL5610 provides a low noise figure of 2.2 dB with a very high OIP3 of more than 38 dBm simultaneously， which delivers a high dynamic range. The ADL5610 provides a gain of 18 dB， which is stable over frequency， temperature， and power supply， and from device to device. The amplifier is offered in the industry-standard SOT-89 package and is internally matched to 50 Ω at the input and output， making the ADL5610 easy to implement in a wide variety of applications. The only external parts required are the input and output ac coupling capacitors， power supply decoupling capacitors， and bias inductor. The ADL5610 has a high ESD rating of ±1.5 kV （Class 1C） and is fully specified for operation across a wide temperature range of ?40°C to +105°C. A fully populated RoHS-compliant evaluation board is available.
